FLIR E5 Pro Thermal Imaging Camera

FLIR E5 Pro Thermal Imaging Camera

The FLIR E5 Pro Thermal Imaging Camera has an IR resolution of 160 x 120 (19,200 pixels) allowing for use in a wide range of industries such as HVAC, industrial and building inspections. When using the FLIR E5 Pro thermal camera, users can use the camera for several inspections including; moisture damage, heat loss, electrical, mechanical and many thermal issues. Users can view temperature measurements from -20ºC to 400ºC (-4°F to 752°F)in two ranges from a minimum distance of 0.36m with an accuracy of ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F.

The FLIR E5 Pro boasts a 3.5 inch LCD colour screen with a 640 x 480 resolution. A 5MP digital camera with an incorporated LED lamp to improve decision-making even in low-light environments. Using Delta T (NFPA 70B compliant), the FLIR E5 Pro has a one-touch level and span, pan and zoom users are also able to add text annotations to images for detailed analysis in the field and at a later time. Images and comments can easily be inserted into reports for both colleagues and customers.

The E5 Pro uses a simple point-and-shoot technique with focus-free optics with a field of view of 33º. Thermographers are shown the Center spot box temperature, with minimum and maximum temperatures also displayed. Several colour palettes can be chosen by the operator (Iron, White Hot, Black hot, Rainbow, Artic, Lava, Rainbow H)

MSX® Image Enhancement

All Ex-Series thermal cameras feature FLIR's unique Multi Spectral Dynamic Imaging (MSX), which adds key details from the onboard visible light camera to the entire infrared image in real time. The result: an all-in-one, undiluted thermal picture with visible light features that lets you instantly recognize where the problematic heat pattern is. MSX is real time so you can see its results immediately in the camera's LCD.

Save Time With 1-Touch Level/Span

1-Touch Level/Span allows you to choose a small area of focus in a thermal image - with one touch of the screen - and the camera will auto-adjust the level and span based on the thermal contrast at that spot in the image. The result: time saved on manual adjustments.

NFPA 70B Compliant - Delta T Measurement Tools

With NFPA 70B compliant Delta T measurement tools now built into Ex-Series cameras (Box1 Max - Spot1 Max, and Box1 Max - Atmosphere Temperature), you can save a lot of time by calculating ∆T on the camera without any additional steps.

Efficient Inspections at Your Fingertips

Add notes from the touchscreen

Featuring a 3.5-inch touchscreen, the FLIR E5 Pro allows you to add detailed annotations to images and save them to the cloud, making it simple to create reports.

Hassle-Free Data Transfer and Sharing with FLIR Ignite

• Desktop Sync eliminates issues created by damaged or missing SD cards and USB cables
• Secure Data Sharing to trusted team for easy collaboration and reporting
• Edit Anywhere allows you or coworkers to create reports on mobile devices, on a browser or desktop

Professional Reports that Help Your Customer and Your Business

The right image analysis and reporting software can greatly improve your business by making it easier for your customers to understand the problem and feel confident that you fixed it.

The FLIR Ignite cloud service allows you to back up images directly to the cloud, organize and edit files, and create simple reports. And for advanced editing and reporting, there's FLIR Thermal Studio Suite: a desktop software offering batch processing, feature-rich measurement tools, and customized reports.

Specification
